Beyond Smile

Unlock a New Era in Dentistry with MetiSmile - Your Gateway to Precision. MetiSmile, SHINING 3D's exclusive facial scanner, redefines clinical diagnosis by capturing facial information swiftly and generating precise 3D models. Boasting powerful hardware and a high-fidelity texture camera, it delivers scan accuracy within 50µm and realistic facial color. The advanced software aligns facial and intraoral scans, offering a comprehensive view for digital smile design. Revolutionize dental treatment, from maxillofacial surgery to aesthetics restoration. Elevate your clinic's capabilities with MetiSmile, the indispensable tool for modern dentistry.

Fast Scan Speed
In 10 seconds this highly perceptive scanner can take photos of patients from multiple angles to simultaneously construct a 3D facial data.

Ortho Simulation
Some of the features of the ortho simulation module include automatic lip extraction and one-click tooth segmentation, etc. The intelligent before and after orthodontic treatment display is enhanced by the integration of the facial scan information.

Mandibular Trajectory Tracking
Using mandibular trajectory tracking, the dentist can acquire dynamic occlusion data. This module includes left and right lateral detection, centric, and open occlusion. It delivers detailed occlusion information for accurate diagnosis, design, and treatment.

Facial Features Measurement & Comparison
The intuitive software is capable of recognizing 3D facial features, measures distances, and enhances treatment planning. These software tools help dentists diagnose and evaluate treatment more effectively. and improves the patient's satisfaction with the treatment plan while adding visual presentation.

Technical Specification

Resolution – Data Acquisition Camera: 1.3 Mega Pixel

Resolution – HD Texture Camera: 5.0 Mega Pixel
Accuracy: 50µm
Field of View: With working distance 500 mm, the FOV is 210 × 270 mm
White LED Color Temperature: 5500 K
Dimension: 215 × 50 × 75 mm
Weight: 800 g
Output: PLY, OBJ, STL
Power Supply (Input): AC100-220 V~, 50/60 Hz, 1.5 A
Power Supply (Output): DC12 V, 7.0 V
Connector: USB 3.0

Recommended PC Configuration

CPU: Intel® Core™ i7-8700 or higher
Memory: Minimum: 16 GB / Recommend: 32 GB
Hard Disk Drive: 256 GB SSD or above
Graphic Card (GPU): NVIDIA® RTX 2060 6 GB or higher
Operating System: Windows 10 (64-bit) or later versions of Windows operating system
Display Resolution: 1920 × 1080, 60Hz or higher
